Milano S
Milano S Lineer
Modern iç mekanlar için mimari lineer LED aydınlatma çözümü.
Standard
220–240V ACON/OFF
Options
DALI24V DC
SELECT MODEL
- IP Rating
- IP20
- Warranty
- 3 Yıl
- Voltage
- 220-240V AC
03
Technical Specifications
Mechanical
- Gövde
- Alüminyum Ekstrüzyon
- Yan Kapaklar
- ABS
- IP Sınıfı
- IP20 / IP54
- Montaj Tipi
- SURFACE,SUSPENDED
- Garanti Süresi
- 3 Yıl
- Gövde Rengi
- SİYAH
Custom RAL colours are available on request in addition to standard finishes.
Optical
- CRI
- ≥70
- Renk Sıcaklığı
- 3000K / 4000K / 6500K
Electrical
- Besleme Gerilimi
- 220–240V AC
04
Variants
| Product Code | Power | Lumens | Efficiency | Length | Beam Angle | CCT | CRI | IP Rating | IK Rating |
|---|---|---|---|---|---|---|---|---|---|
| LMSS-3230-20 | 32 W | 3,360 lm | 105 lm/W | 1,000 mm | — | 3000K | 70 | IP20 | — |
| LMSS-3240-20 | 32 W | 3,520 lm | 110 lm/W | 1,000 mm | — | 4000K | 70 | IP20 | — |
| LMSS-3265-20 | 32 W | 3,520 lm | 110 lm/W | 1,000 mm | — | 6500K | 70 | IP20 | — |
| LMSS-3230-54 | 32 W | 3,360 lm | 105 lm/W | 1,000 mm | — | 3000K | 70 | IP54 | — |
| LMSS-3240-54 | 32 W | 3,520 lm | 110 lm/W | 1,000 mm | — | 4000K | 70 | IP54 | — |
| LMSS-3265-54 | 32 W | 3,520 lm | 110 lm/W | 1,000 mm | — | 6500K | 70 | IP54 | — |
Selected variant: LMSS-3230-20
05
Downloads
Teknik Çizim
Technical Drawing · TR · vv1
06
Applications
Facade Lighting
Historical Buildings
Hotels
Landscape
Bridges
Public Areas
Commercial Buildings
